Pioneer GM-DX104

Bridgable:

Yes



Class:

D



Grounding System:

Negative



Power Source:

14.4 V DC (10.5 V to 16.0 V)



Protection Control system:

Yes



Terminal Type:

Removable



Unit Weight:

1.2 lbs



Allowable Load Impedance:

2 ohm to 8 ohm allowable



Avg Current Consumption (amps x #ch):

1.6 A (4 Ohms x 4ch),1.6 A (2 Ohms x 4ch),1.6 A (4 Ohms x 2ch Bridged)



Continuous-Power-Output:

45 W x 4-Channel - 4 Ohm, 90 W x 2-Channel - 4 Ohm Bridged



Frequency Response Channel:

10Hz to 40kHz (+0dB,-3dB) A/B Ch



Fuse Rating:

15 A



High-Pass Crossover frequency:

80 Hz (LPF/OFF/HPF)



High-Pass Slope (dB/octave):

-12 dB/oct



Low-Pass Crossover frequency:

80 Hz (LPF/OFF/HPF)



Low-Pass Slope (dB/octave):

-12dB/oct



Maximum Power Output:

100 W x 4-Channel (4 Ohm),200 W x 2-Channel (4 Ohm Bridged)



RCA Inputs:

4-Channel



Signal to Noise:

93 dB



Speaker Line input Sensor:

Yes
