Ground Zero GZUA 2SQ

2-channel high-end class AB amplifier

High-performance 2-channel SQ amplifier

Output power:

- 2x 175 W RMS @ 4 ohms

- 2x 300 W RMS @ 2 ohms

- 2x 485 W RMS @ 1 ohm

- 1x 1180 W max @ 2 ohms (bridged)

1 ohm stable (stereo operation)

THD+N 0.005%

Frequency Response 10 Hz - 70kHz ( -3dB )

LPF: 20 Hz - 400 Hz / 200 - 4000 Hz ( x10 )

HPF: 20 Hz - 400 Hz / 200 - 4000 Hz ( x10 )

Band Pass Filter 20 Hz - 4000Hz ( x10 )

SNR:  110dB

Damping Factor: 800

Adjustable BIAS setting

Adjustable high and low pass filters with wide bandwidth

Bandpass function with activated high and low pass filter

Adjustable input sensitivity

Power on delay

Phase position control

Boss Boost control (0 - 1 2dB @ 45 Hz)

Temperature / short circuit / overload protection

Wired Bass Level Remote

Dimensions:

209 x 48 x360 mm
