HELIX V EIGHT DSP MK2

8-channel amplifier 8 x 75 Watts @ 4 Ohms with integrated 10 channel DSP

• Eight speaker outputs with up to 160 Watts RMS into 2 Ohms

• New “Pure Class GD” concept for outstanding sound quality combined with best possible efficiency

• Cutting-edge, extremely powerful “fixed point” Audio DSP with 64 Bit resolution and 1.2 billion MAC operations per second

• ACO – Advanced 32 Bit CoProcessor platform for system and DSP features like:

ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals

SFX sound effects – Augmented Bass Processing, StageXpander, RealCenter & Co.

• Two processed RCA outputs

• Inputs: 6 x RCA, 8 x Highlevel with up to 32V RMS input sensitivity, optical SPDIF input and Remote in.

• Smart highlevel input with ADEP.3 circuit (Advanced Diagnostics Error Protection)

•Virtual Channel Processing (VCP) allows even more flexible configuration for highly complex sound systems

• HELIX Extension Card slot (HEC) for additional input / output modules like Bluetooth® Audio Streaming

• Compact design with low heat dissipation thanks to extraordinary efficiency

• Dimensions (H x W x D): 44 x 220 x 180 mm / 1.73 x 8.66 x 7.09”
