Apraksts

Compatibility:



    CITROREN C2

    CITROREN C3

    CITROREN C4 II

    CITROREN C4 PICASSO

    CITROREN C5

    CITROREN DS3

    CITROREN DS4 II

    PEUGEOT 207

    PEUGEOT 207 SW

    PEUGEOT 307

    PEUGEOT 308

    PEUGEOT 407

    PEUGEOT 508

    PEUGEOT RCZ 5008

    PEUGEOT RCZ 3008

    TOYOTA



Phantom power supply



Screwable mast: yes



Mast Lenght: 40 cm



Cables lenght : 120 cm



Frequency FM: 76 - 110 MHz,



Frequency AM: 525 - 1700 KHz,



Gain FM: +24 dB,



Gain AM: +20 dB,



Impedance AM/FM 75Ω





GPS band parameters:



Frequency range 1575.42 MHz ± 1.02 MHz

V.S.W.R 1.5: 1

Bandwidth> 10 MHz

50 Ω resistance

5dBic gain

RHCP polarization



GPS Low Noise Amplifier:



Frequency range 1575.42 MHz ± 1.02 MHz

DC voltage 3 - 5 V.

Gain 28 ± 3 dB

Cut-off ranges ≥25dB ​​(frequency range + 100MHz)

≥40dB (frequency range –100 MHz)

V.S.W.R. output 1.5

NSR 1.2

DC 10.5 mA



Summary parameters of GPS antenna and amplifier:



Frequency range 1575.42 MHz ± 1.02 MHz

V.S.W.R. output 1.5

Gain 28 ± 3dBic

50 Ω resistance

Temp. work -25ºC ~ + 65ºC
