AI-SONIC S2-A500.1 with S2-BASS KNOB

RMS POWER (1ohm) 12v THD 0.5% 500W

RMS POWER (2ohm) 12v THD 0.5% 350W

RMS POWER (4ohm) 12v THD 0.5% 220W

T.H.D 0.5%

BANDWIDTH: 10-200 Hz

S/N RATIO(A-WEIGHTED): 90dB

INPUT SENSITIVITY: 0.35-6V

LOW PASS: 50-200 Hz

SUBSONIC: 10-50Hz

CROSSOVER SLOPE: 12dB/24dB /oct

BASS BOOST: 0-12dB(@45Hz)

POWER FUSE: 30A•2

Cable fitting size:

+12V = 20mm2

GND = 20mm2

REM = 6mm2

SPEAKER = 6mm2

Current Draw (Max): 57A

DIMENSIONS W: 183mm / (7.2IN)

H: 60mm / (2.4 IN)

L: 274mm / (10.8 IN)
