Apraksts

Power RMS / max.      P     100 / 150 Watts

(highpass > 300 Hz at 24 dB/Oct.)

Impedance      Z     4 Ω

DC resistance      Re     3.4 Ω

Resonance frequency      Fs     80 Hz

Mechanical Q factor      Qms     2.21

Electrical Q factor      Qes     0.33

Total Q factor     Qts     0.29

Compliance     Cms     1220 μm/N

Equivalent air volume     Vas     2.09 L

Force factor      B*I     4.1 Tm

Efficiency 1 W / 1 m     SPL     87 dB

Cone area      Sd     35 cm²

Moving mass      Mms     3.3 g

Cone material           Paper cone with “MicroSphere” coating consisting of micro ceramic hollow spheres embedded in a polymer layer

Mechanical resistance      Rms     0.74 kg/s

Voice coil diameter     ø     25 mm / 1"

Voice coil winding height           6 mm / 0.2"

Max. linear excursion      Xmax     +/- 1.5 mm

Outer diameter     ø     92 mm / 3.6"

Installation diameter     ø     76 mm / 3.0"

Installation depth           34 mm / 1.3"



Recommended enclosure volumes

Sealed box with minimum 250 ml net volume



Net volumes      Recommended DSP / amplifier settings

0.4 liter (System resonance: 200 Hz)      Crossover frequency: 350 Hz

Min. filter slope: 12 dB/Oct.

0.8 liter (System resonance: 155 Hz)      Crossover frequency: 300 Hz

Min. filter slope: 12 dB/Oct.

1.2 liter (System resonance: 140 Hz)      Crossover frequency: 250 Hz

Min. filter slope: 24 dB/Oct.







Note: The enclosure should always be filled with appropriate damping material.
