ALPINE BBX-T600

Max Power Output Ratings

Total Max Power: 300W

RMS Power Ratings

Per Channel into 4ohms (≤1%THD+N): 2 x 50W

Per Channel into 2ohms (≤1%THD+N): 2 x 70W

Bridged into 4ohms (≤1%THD+N): 1 x 130W

Sound Tuning

Crossover Frequency (Variable, OFF/LPF/HPF Selectable)

1/2 Ch: LP: 50Hz – 250Hz HP: 80Hz – 1.2kHz

EQ (Equalizer): Bass EQ Fixed Frequency 45 Hz, Q=0.5, Variable Gain 0dB to +12dB

Dimensions

Footprint: 250 mm x 52 mm x 240 mm

General

Power Requirements: 14.4 V DC (11 V to 16 V)

Input Sensitivity: 0.2 - 8.0 V

Frequency Response: 5 Hz - 50 kHz (+ 0,-3 dB)

Speaker Impedance: 4 or 2 Ω

Signal to Noise: S/N Ratio (IHF A Weighted, Reference: rated power into 4ohms) 95 dB

Weight: 1.9 Kg
