Apraksts


  • 5-channel Class GD amplifier with integrated 7-channel DSP

  • Very compact dimensions and low heat dissipation thanks to maximum efficiency

  • Two power options: “HighPower” mode for maximum performance and “MidPower” mode with reduced output power and low power consumption for Plug & Play applications

  • Extremely powerful “fixed point” audio DSP with 56 Bit resolution

  • Optical input in SPDIF format with sampling rates between 6 and 96 kHz

  • Automatic remote switch

  • Smart highlevel input with ADEP circuit

  • Freely configurable 2-channel PreOut for the connection of additional amplifiers

  • Subwoofer connection cable for MATCH Plug & Play and conventional subwoofers included in delivery

  • Control input for optional cable remote control
































































































































    Output power RMS / max.
    - @ 4 Ohms HighPower mode: 4 x 60 / 120 Watts (Front/Rear channels)
    MidPower mode: 4 x 35 / 70 Watts (Front/Rear channels)
    - @ 2 Ohms
    - @ 1 Ohm
    - bridged @ 4 Ohms
    - bridged @ 2 Ohms
    - Subwoofer output @ 4 Ohms 1 x 90 / 180 Watts
    - Subwoofer output @ 2 Ohms 1 x 160 / 320 Watts
    Amplifier technology Class GD
    Inputs 4 x Highlevel speaker input
    1 x Optical SPDIF (6 - 96 kHz)
    1 x Remote in
    Input sensitivity 11.2 Volts
    Input impedance RCA / Cinch
    Input impedance highlevel 13 Ohms
    Outputs 5 x Speaker output
    1 x Line Out (3.5mm stereo headphone plug)
    1 x Remote Out
    Output voltage RCA / Cinch 3 Volts RMS
    Frequency response 20 Hz - 20,000 Hz
    DSP resolution 56 Bit
    DSP power 172 MHz
    Sampling rate 48 kHz
    DSP type Audio signal processor
    Signal converters A/D: Asahi Kasei
    D/A: Asahi Kasei
    Signal-to-noise ratio digital input > 105 dB (A-weighted)
    Signal-to-noise ratio analog input > 99 dB (A-weighted)
    Distortion (THD) < 0.03 %
    Damping factor > 50
    Operating voltage 10.5 Volts (max. 5 sec. down to 6 Volts)
    Current draw 280 mA
    Max. remote output current 500 mA
    Fuse 1 x 30 A Maxi-fuse (APX)
    Additional features Fully stabilized internal power supply with Start-Stop capability, 56 Bit digital signal processing, internal memory for two different sound setups, USB input, remote control input, stereo Line Out
    Dimensions (H x W x D) 35 x 85 x 110 mm /
    1.34 x 3.35 x 4.33"
