DD Audio C-C6.5C-XO

Power Handling:

Rated Pink Noise Tested: 65w

Peak Capacity Power Tested: 150w



X-Over Information:

Crossover Frequency: 1600Hz

High Pass Filter Slope: -12dB/Oct

Low Pass Filter Slope: -6dB/Oct



Nominal Impedance Zn:

Tweeter: 3.0Ω

Midwoofer: 2.0Ω



Resonance Frequency Fs:

Tweeter: 582.521Hz

Midwoofer: 49.374Hz



Qms:

Tweeter: 12.164

Midwoofer: 3.912



Qes:

Tweeter:v0.965

Midwoofer: 0.359



Qts:

Tweeter: 0.894

Midwoofer: 0.329



Frequency Response (-6dB) Free Air:

60~40,000Hz



Sensitivity @ 1W / 1M (±3dB):

89.6dB



Voice Coil Diameter:

Tweeter: 0.72 Inch / 18.4 mm

Midwoofer: 1.0 Inch / 25.5 mm



Mounting Information



Overall Diameter:

Tweeter:2.08 Inch / 53 mm

Midwoofer: 6.57 Inch / 167 mm



Cutout Diameter:

Tweeter: 1.76 Inch / 44.6 mm

Midwoofer: 5.63 Inch / 143 mm



Total Depth:

Tweeter: 1.08 Inch / 27.5 mm

Midwoofer: 2.08 Inch / 53 mm



Mounting Depth:

Tweeter: 0.67 Inch / 17 mm

Midwoofer: 1.69 Inch / 43 mm
