Apraksts




Max Power Output Ratings






  • Total Max Power: 1500W





RMS Power Ratings






  • Per channel into 4 Ohms: CH 1-4 (@14.4V ≤1%THD+N) 75W x 4

  • Per channel into 4 Ohms: Subwoofer (@14.4V ≤1%THD+N) 250W x 1

  • Per channel into 2 Ohms: CH 1-4 (@14.4V ≤1%THD+N) 100W x 4

  • Per channel into 2Ohms: Subwoofer (@14.4V ≤1%THD+N) 350W x 1

  • Bridged into 4ohms, 14.4V (@14.4V ≤1%THD+N) 200W RMS x 2





Sound Tuning






  • Crossover (HPF): 50 - 400 Hz , -12 dB/oct.

  • Crossover (Subwoofer, LPF): 50 - 400 Hz, -24 dB/oct.

  • Equalizer (Bass EQ): 0 to +12dB (Subwoofer, fc=50Hz) Variable

  • Subsonic Filter: Subwoofer Variable, 8-40Hz (-24dB / oct )





Dimensions






  • Heat Sink (WxHxD) mm: 270mm x 165mm x 50.8mm





General






  • Power Requirements: 14.4V DC (11 - 16V)

  • Input Sensitivity Subwoofer (RCA Input): 0.1 - 4.0V

  • Input Sensitivity CH 1-4 (RCA Input): 0.2 - 4.0V

  • Input Impedance: >10k ohms

  • Frequency Response Subwoofer (+0, -3dB: 1W into 4 ohms): 8Hz - 400Hz

  • Frequency Response CH 1-4 (+0, -3dB: 1W into 4 ohms): 8Hz - 45kHz

  • Frequency Response Subwoofer (+0, -1dB: 1W into 4 ohms): 10Hz - 300Hz

  • Frequency Response CH 1-4 (+0, -1dB: 1W into 4 ohms): 10Hz - 30kHz

  • THD+N (10W into 4 ohms): ≤0.02%

  • THD+N (Rated Power into 4 ohms): ≤0.07%

  • Damping Factor Subwoofer (10W into 4 ohms at 100Hz): >1000

  • Damping Factor CH 1-4 (10W into 4 ohms at 100Hz): >500

  • Signal to Noise Subwoofer (Rated Power into 4 ohms): >110dB

  • Signal to Noise CH 1-4 (Rated Power into 4 ohms): >105dB

  • Weight: 2.76kg
